Mielta Fantom BLE Fuel Level Sensor
Category: Wireless Fuel Monitoring System
Tag: Mielta Fantom Fuel Level Sensor
Smart, Wireless & Precise Fuel Monitoring
The Mielta Fantom BLE is a next-generation capacitive fuel level sensor designed for wireless fuel monitoring in vehicles and stationary tanks. Using Bluetooth Low Energy (BLE) and advanced diagnostic features, it delivers accurate fuel data, detects tampering, and simplifies installation.
Key Features
| Model | Fantom |
|---|---|
| Brand | Mielta |
| Sensor Type | Capacitive |
| Accuracy | 90 – 95% |
| Operating Temperature | -40 to +85 °C |
| IP Protection | IP67 |
| Inbuilt Flash Memory | 4 MB |
| Housing Dimensions | 80 x 80 x 25 mm |
Wireless & Easy to Use
- Uses Bluetooth Low Energy 5.0
- Battery-powered, no external wiring needed
- Fast, cable-free installation process
- Fully configurable via the Mielta DM mobile app
Advanced Protection & Diagnostics
- Sabotage detection with shielding sensor
- Logs metal interference events with time and duration
- Self-diagnosis system detects calibration issues, fuel quality changes, and water contamination
- Built-in accelerometer checks vehicle inclination for accurate readings
- Data stored in internal memory even without terminal connection
Fuel Compatibility
Compatible with a wide range of fuel types including gasoline, eco-gasoline, diesel, and biodiesel blends.
Energy Efficiency
The adaptive power-saving system reduces energy consumption during transport or when the device is horizontal.
Installation
- Adjust sensor for “empty-full” before installation
- Calibrate the sensor after installation using the Mielta DM app
- Connect wirelessly to compatible monitoring systems
Use Cases
- Commercial vehicle fleets
- Fuel delivery systems
- Diesel generator tanks
- Construction and agricultural equipment
